ELEGOO Upgraded UNO R3 Project Most Complete Starter Kit w/Tutorial Compatible with Arduino IDE (63 Items) V2.0
11 sold in last 24 hours
- UPGRADED ALL-IN-ONE SENSOR SHIELD: Plug compatible modules into clearly labeled ports to reduce loose wiring and connection errors. The V2.0 shield supports multi-module builds while keeping the breadboard available for custom circuits
- STRUCTURED LEARNING FROM BASICS TO PROJECTS: Separate PDF lessons cover setup, C-language fundamentals, libraries, code references, FAQs and Ubuntu development. Current tutorial files are available through ELEGOO download resources, so an optical drive is not required
- 34 GUIDED PROJECTS, MORE WAYS TO BUILD: Progress from LEDs and displays to Dice Roll, Retro Snaker, Memory Game, Alarm Clock, Time Recorder and induction night light projects that combine multiple sensors and modules
- 250+ PIECES ACROSS 71 COMPONENT TYPES: Includes the UNO R3 controller, LCD1602, RC522 RFID, ultrasonic and PIR sensors, DHT11, GY-521, motors, keypad, relay, displays, breadboard, jumper wires, power adapter and essential electronic parts
- ORGANIZED FOR REPEATED USE: The compartment case protects small parts and makes components easier to find between lessons. Pre-soldered headers on key modules reduce setup time. Designed for teens age 14+, adults, classrooms, makers and electronics hobbyists
Tags |
Estimated shipping
Select a product to estimate shipping.ELEGOO UNO R3 Starter Kit V2.0: Easier Connections and Expanded Learning
Want to learn how to work with electronics and programming but need a little help? You've come to the right place!
ELEGOO UNO R3 Starter Kit V2.0 provides an open-source electronics prototyping platform based on flexible, easy-to-use hardware and software, which evolves the user from beginner to professional level .
The differences between V1.0 and V2.0:
We re-design the layout of the tutorial. In the V1.0 tutorial, all the lessons are in one PDF file. And in the V2.0 tutorial, each lesson has a separate PDF file.
We add more code references/explanations to the V2.0 tutorial.
We add more complex projects (part 4) in the V2.0 tutorial. In the previous lessons, only one sensor/module will be used. In these lessons, it uses multiple sensors/modules to build the project.
The V1.0 starter kit has a prototype expansion board and it usually uses to solder some fixed circuits on it. The V2.0 starter kit uses a “all-in-one-sensor-shield” to replace the prototype expansion board. In the V2.0 tutorial, the lessons in part 4 need to connect more than one sensor to the controller board. The “all-in-one-sensor-shield” can help to build the project by easily plugging and unplugging the sensor/module.
Quantity and quality are both important here in ELEGOO UNO R3 starter kit. The most essential parts in this kit are UNO R3 controller board and expansion board, which is a perfect clone with excellent product finish compatible with electronics projects.
Besides, we offer other over 60 kinds of components and sensors from small parts like LED diodes, resistors and potentiometers to big parts like LCD1602, RFID module and 830 tie-points breadboard, which meet your demands for your different projects either it is simple or complex.
Sturdy quality is definitely the most important thing to ELEGOO even with so many components provided we never compromised on the quality.
Instead we keep improving our product quality in our own factory and we produce the products by ourselves under high standards and strict quality control. Pins and wires on some of the parts like LCD1602 and motors have been pre-soldered which is very convenient and saves your time.
Starter kit for Everyone to Learn Electronics, Programming and Robotics
Electronics is not as complicated as you imagine especially with ELEGOO UNO R3 Starter Kit V2.0 . For advanced users like professional lab engineers, electronics engineering students and experienced electronics hobbyists, they can use this kit to do various kinds of tests and experiments with so many sensors available at hand.
What about novice users who don't have any electronics knowledge? Fear not amigo. Just follow our tutorial enclosed and step by step you will come to realize that learning electronics is more fun than you ever expected with this amazing sensor kit.
It’s a good choice and perfect kit for teens, adults or whoever is obsessed with electronics, programming or robotics to take their first steps on electronics journey!
Component Listing:
5 × White LED; 5 × Yellow LED; 5 × Blue LED; 5 × Green LED; 5 × Red LED; 1 × RGB LED
5 × 22 pF Ceramic Capacitor; 5 × 104 Ceramic Capacitor; 2 × Photoresistor; 1 × Thermistor; 5 × Diode Rectifier (1N4007)
2 × Electrolytic Capacitor (10 μF, 50 V); 2 × Electrolytic Capacitor (100 μF, 50 V)
5 × NPN Transistor (PN2222); 5 × NPN Transistor (S8050); 1 × Tilt Switch; 5 × Button (small)
1 × 1-Digit 7-Segment Display; 1 × 4-Digit 7-Segment Display; 1 × Sound Sensor Module; 1 × LCD1602 Module ( with pin header)
1 × IC L293D; 1 × IC 74HC595; 1 × Active Buzzer; 1 × Passive Buzzer; 1 × RTC Module; 1 × DHT11 Temperature and Humidity Module
2 × Potentiometer; 1 × Rotary Encoder Module; 1 × Joystick Module; 1 × Keypad Module; 1 × 5 V Relay; 1 × IR Receiver Module
1 × UNO R3 Controller Board; 1 × Breadboard; 1 × Servo Motor (SG90); 1 × Stepper Motor; 1 × ULN2003 Stepper Motor Driver Board
1 × ELEGOO UNO ALL IN ONE Sensor Shield; 1 × Power Supply Module Warning: Do not apply more than 9 V to the power supply module
1 × HC-SR501 PIR Motion Sensor; 1 × Ultrasonic Sensor; 1 × GY-521 Module; 1 × 3V Servo Motor; 1 × MAX7219 Module
1 × Remote; 1 × 9 V, 1 A Power Supply; 1 × 65 Jumper Wires; 1 × Water Level Sensor; 1 × USB Cable; 1 × 9 V Battery with DC; 1 × RC522 RFID Module;
10 × Resistor (10R); 10 × Resistor (100R); 30 × Resistor (220R); 10 × Resistor (330R); 10 × Resistor (1K); 10 × Resistor (2K); 10 × Resistor (5K1); 10 × Resistor (10K); 10 × Resistor (100K); 10 × Resistor (1M)
20 × Female-to-Male Dupont Wires and 10 × Female-to-Female Dupont Wires
74HC595 Shift Register and LEDs
74HC595 is a Serial to Parallel Converter which has eight outputs (perfect) and three inputs that you use to feed data into it a bit at a time. This chip makes it a little slower to drive the LEDs (you can only change the LEDs about 500,000 times a second instead of 8,000,000 a second) but it's still really fast, way faster than humans can detect, so it's worth it.
74HC595 shift register is a type of chip that holds what can be thought of as eight memory locations, each of which can either be a 1 or a 0. To set each of these values on or off, we feed in the data using the 'Data' and 'Clock' pins of the chip.
LCD1602 Display Module
LCD1602 module is a display that has an LED backlight and can display two rows with up to 16 characters on each row. You can see the rectangles for each character on the display and the pixels that make up each character. The display is just white on blue and is intended for showing text.
Lining up the display with the top of the breadboard helps to identify its pins without too much counting, especially if the breadboard has its rows numbered with row 1 as the top row of the board. Do not forget, the long yellow lead that links the slider of the pot to pin 3 of the display. The 'pot' is used to control the contrast of the display.
DC Motors and L293D Transistor
In this project you will learn how to control a small DC motor using an UNO R3 and a L293D transistor, which is a very useful chip. It can actually control two motors independently. We are just using half the chip in this lesson, most of the pins on the right hand side of the chip are for controlling a second motor.
The L293D is a quadruple high-current half-H driver designed for bidirectional control of DC motors and other inductive loads. It supports continuous output current of up to 600 mA per channel over a 4.5–36 V supply range.
